Implant motor
APPLEDENAL Implant Motor Functions:
A.7 steps to implant；1.It's easy to use because the LCD color screen clearly displays each step of the operation. (without secondary operation interface, easy to get familiar with)
B. The implant steps are graphically displayed, making it more intuitive 33 Custom Programs
C. 1:1, 1:5, 1:16, 20:1 optional ratios, multi-functional in one
D. The matching surgical straight handpiece can be used for maxillary sinus lift surgery
E. It can be equipped with different contra-angle machines, such as 1:1, 1:5, and 16:1, which can be used for cutting, grinding teeth, and for extraoral fine-tuning after implantation and crowning
Product Description
Advantages of implant motor:
1.Precise torque；1.Large torque Max can bear 70N.cm makes difficult surgeries easier
2. Precise torque control makes operation more assured 2.Longer lifespan；German imported motor, ultra-long lifespan, 3-year warranty；Strong stability；1. Less jitter, more stable
3. Super quiet - presented in video - long bur; with decibel tester；Bright Lights；
4. It's friendly for female dentist to operate 5Imported bearings；Special heat treated gears Special heat treated gears；Good vision, more convenient and safer operation
MODEL: AE60 AE62
Specifications |
| |
Model | Ae62 | Ae60 |
Main system size | L245*W278*H110mm | |
Input voltage | 230VAC | 115VAC |
Allowed voltage fluctuation | ±10% | |
Rated current | 0.1A-0.8A | |
Supply frequencies | 50Hz/60Hz | |
Power fuse | 2*250V-T1.6AH | |
Maximum power consumption | 170VA | |
Motor rated working voltage | DC32V | |
Motor rotation mode | Forward/reverse rotation | |
Motor rotation speed | 200 rpm to 40,000 rpm | |
Size of motor | Φ21.7mm x height 70.5mm | |
Sterilization method | High temperature and high pressure steamsterilization at 134° for 5 minutes | |
Hanging maximum allowed load | ≤1.5KG | |
Features |
| |
Extract a Tooth/Restorative/Tooth Polishing/Caries Removal/Implant/Pulp Opening | ||
Motor
Model | M1 |
Specifications |
|
Type | No carbon brushes, built-in water spray |
Maximum torque | 5.5 N-cm |
Rotation speed | Specifications 200-40000rpm |
Weight | 72g |
Connection | IS0 3964 |
Light | LED |
Autoclave | Motor head can be sterilized(with protective cap) |
Noise | ISO14457 |
Size of motor | 20mm |
Product name | Electric motor |
Handpiece
Speed ratio | 20:1 | 1:1 |
Connection | Compatible with all kindof E type connectors | |
Rotating speed | 10-1000 rpm 10-50rpm | 200-40000 rpm |
Size of motor | Φ9.8 x H14.3 mm | |
Noise | ≤80dB | |
Light | Fiber optic | |
